GoPDFKit

Benchmark Snapshot

Local benchmark run on 12th Gen Intel(R) Core(TM) i7-12700 with 20 logical CPUs. Results below are from:

make bench-generation-core

For a generation-only suite without HTML examples:

make bench-generation-core-ci

Workload	Mode	ns/PDF	PDF/sec	Memory/PDF	Allocs/PDF	Output size	Total allocated
Text table	40 workers	69,243	14,442	321,953 B	1,326	43,591 B	5,288 MB
Long text	40 workers	26,673	37,492	87,435 B	257	8,281 B	3,468 MB
Baseline no-compliance, uncached image	40 workers	71,916	13,905	641,572 B	1,628	59,506 B	9,984 MB
Baseline no-compliance, no image	40 workers	60,138	16,628	446,967 B	1,407	50,268 B	9,328 MB
Baseline no-compliance, cached image	40 workers	61,553	16,246	458,651 B	1,495	59,338 B	8,531 MB
Baseline no-compliance, signed uncached image	40 workers	227,397	4,398	1,146,568 B	1,943	93,298 B	7,640 MB
Baseline no-compliance, signed cached image	40 workers	177,336	5,639	961,381 B	1,809	93,074 B	7,243 MB
UTF-8 text	40 workers	639,110	1,565	7,009,282 B	15,386	44,370 B	11,792 MB
UTF-8 text, cached font	40 workers	208,604	4,794	1,075,476 B	4,176	44,370 B	7,047 MB
Text compression, best speed	40 workers	62,747	15,937	220,349 B	1,329	8,187 B	4,035 MB
Text compression, best compression	40 workers	126,533	7,903	219,738 B	1,329	7,726 B	2,096 MB
Four uncached images	40 workers	150,022	6,666	1,367,486 B	1,416	15,073 B	11,109 MB
Four cached images	40 workers	6,057	165,085	62,593 B	245	15,017 B	11,279 MB
SVG	40 workers	7,526	132,876	42,292 B	134	7,797 B	7,913 MB
Templates	40 workers	51,599	19,380	249,557 B	541	9,909 B	5,553 MB
Imported PDF pages	40 workers	5,958	167,843	40,406 B	329	1,938 B	9,277 MB
Protection	40 workers	8,567	116,722	57,407 B	356	5,047 B	8,883 MB
Attachments	40 workers	21,658	46,173	48,429 B	229	8,383 B	2,516 MB

The 40-worker rows use a fixed explicit worker count, so they measure concurrent PDF generation throughput with the same workload pressure across machines. Signed rows include PDF output plus detached CMS signing; the benchmark certificate and key are prepared outside the timed loop. Compliance rows measure generation only; external veraPDF and Arlington validation are separate CI steps. The raw Go benchmark output also includes pdf/s, pdf_bytes, and total_MB metrics from the timed loop.

Additional compiled HTML/parser medians from:

go test ./document -run '^$' -bench 'BenchmarkHTMLTokenize|BenchmarkCompileHTMLLargeFragment|BenchmarkGenerationHTML(SelectorHeavyCompiled|DataImageHeavy|DataImageHeavyCompiled|LargeTableCompiled|WideTableCompiled|SVGHeavyCompiled)$' -benchmem -count=5

Workload	ns/op	Ops/sec	Memory/op	Allocs/op
Tokenizer, small attributes	313	3,190,810	432 B	3
Tokenizer, large fragment	459,518	2,176	1,130,706 B	3,125
CompileHTML, large fragment	1,995,077	501	3,105,631 B	11,384
Selector-heavy compiled HTML render	626,999	1,595	193,069 B	1,629
Data-image-heavy compiled HTML render	209,107	4,782	137,117 B	1,027
Data-image-heavy non-compiled HTML render	310,302	3,223	233,747 B	1,439
Large table compiled HTML render	5,127,521	195	5,227,244 B	11,515
Wide table compiled HTML render	1,461,651	684	1,584,045 B	3,538
SVG-heavy compiled HTML render	452,602	2,209	391,676 B	1,762

The latest local profiles used for the tokenizer and compiled HTML work are /tmp/gopdfkit-tokenizer.cpu, /tmp/gopdfkit-selector-heavy.cpu, and /tmp/gopdfkit-data-image-heavy.mem.

GoPDFKit is an MIT-licensed Go library for generating PDFs directly from Go code. It keeps an FPDF-style API for familiar page/text/drawing workflows, with additional helpers for HTML fragments, imported pages, signing, thumbnails, and structured document models.

The root gopdfkit package is intentionally small. It exposes the default constructor and public aliases. Import github.com/cssbruno/gopdfkit/document when you need the full API.

Install

go get github.com/cssbruno/gopdfkit@latest

Quick Start

package main

import "github.com/cssbruno/gopdfkit"

func main() {
	pdf := gopdfkit.New()
	pdf.AddPage()
	pdf.SetFont("Helvetica", "B", 16)
	pdf.Cell(40, 10, "Hello, world")
	if err := pdf.OutputFileAndClose("hello.pdf"); err != nil {
		panic(err)
	}
}

Use document.NewWithOptions when generation defaults should be configured at construction time:

pdf := document.NewWithOptions(document.Options{
	OrientationStr: "P",
	UnitStr:        "mm",
	SizeStr:        "A4",
	Optimize:       true,
})

Optimize: true selects best zlib compression for generated page and template streams. It is not a full PDF optimizer for images, object streams, fonts, or arbitrary existing PDFs.

Current Capabilities

GoPDFKit currently supports:

• PDF generation with pages, margins, headers, footers, page boxes, and page breaks
• Standard PDF fonts and UTF-8 TrueType fonts
• Text, cells, multicells, aligned writing, styled paragraphs, links, bookmarks, and aliases
• Tables, reports, invoices, static filled form documents, and shared document model rendering
• Drawing primitives: lines, rectangles, rounded rectangles, arcs, Bezier curves, polygons, paths, clipping, transforms, transparency, gradients, spot colors, and layers
• JPEG, PNG, GIF, WebP, SVG, data-image, QR-code PNG generation, and thumbnail workflows
• Controlled HTML/CSS fragment rendering through HTMLNew, including text styles, spacing, borders, border radius, backgrounds, and simple box shadows
• Templates and imported PDF pages
• Page workflows built from imported pages: merge, split, reorder, rotate, 4-up layout, template overlay, and watermark overlay
• Attachments, metadata, XMP metadata, JavaScript actions, password protection, PDF signing, CMS signature verification, and lightweight PDF inspection

Current Limits

These are not implemented as general-purpose features:

• Full browser-compatible HTML/CSS layout
• JavaScript page rendering
• DOCX conversion
• Interactive AcroForm field creation
• Filling, flattening, or FDF-merging existing interactive forms
• Unlocking, decrypting, or removing passwords from existing PDFs
• Arbitrary PDF editing, OCR, or content rewriting
• General-purpose semantic text extraction from every possible PDF encoding

Imported page support is intentionally narrow: classic xref-table PDFs, unencrypted documents, and pages whose content streams are unfiltered or FlateDecode-compressed. PDFs that use xref streams or object streams are reported as unsupported.

Password protection applies to newly generated output. The permission flags are advisory because PDF readers decide how strictly to enforce them.

Compliance Metadata

document.SetComplianceMetadata can generate PDF/A-4, PDF/UA-2, Arlington, and XMP metadata foundations. PDF/UA-2 mode enables tagged PDF output with /StructTreeRoot, /ParentTree, page and annotation /StructParent entries, MCIDs, text/link/image marked content, link annotation /OBJR references, image alternate text, artifact spans for drawing/raw decorative content, and semantic structure containers for HTML and shared document renderer lists and tables. Templates and imported pages are treated as artifacts unless their content is rendered through semantic APIs before placement. PDF/A mode also enforces the high-risk generation blockers currently known to the library: no encryption, no JavaScript, an ICC output intent, embedded UTF-8 fonts with Unicode maps, and PDF/A-4f or PDF/A-4e when attachments are present.

This is not a full validator replacement. Use make compliance-fixtures and make compliance-validate with external validators for standards checks. See compliance-validation.md.

Strict validation can be run with Dockerized veraPDF plus the Arlington REST service:

REQUIRE_COMPLIANCE_TOOLS=1 \
SRGB_ICC=/usr/share/color/icc/colord/sRGB.icc \
VERAPDF_DOCKER_IMAGE=verapdf/cli:v1.30.2 \
VERAPDF='tools/verapdf-docker.sh 0' \
PDFUA_CHECKER='tools/verapdf-docker.sh ua2' \
ARLINGTON_CHECKER='tools/arlington-validate.sh' \
ARLINGTON_URL='http://localhost:8080' \
make compliance-validate

Examples

Runnable examples live under examples/. They write PDFs to assets/generated/pdf/examples. For compact code snippets grouped by workflow, see doc/generation-examples.md.

Workflow	Command	Output
Hello world	go run ./examples/hello-world	hello-world.pdf
Drawing primitives	go run ./examples/drawing	drawing.pdf
Headers and footers	go run ./examples/headers-footers	headers-footers.pdf
Report	go run ./examples/report	gopdfkit-report.pdf
Structured report	go run ./examples/structured-report	structured-report.pdf
Table report	go run ./examples/table-report	gopdfkit-tables.pdf
Invoice	go run ./examples/invoice	invoice.pdf
Styled paragraphs	go run ./examples/styled-paragraphs	styled-paragraphs.pdf
HTML fragment	go run ./examples/html-fragment	html-fragment.pdf
HTML CSS styles	go run ./examples/html-css-styles	html-css-styles.pdf
HTML images and SVG	go run ./examples/html-images	html-images.pdf
HTML tables	go run ./examples/html-tables	html-tables.pdf
HTML template values	go run ./examples/html-template	html-template.pdf
Manual pagination	go run ./examples/pagination-table	pagination-table.pdf
Document pagination	go run ./examples/pagination-document	pagination-document.pdf
Images	go run ./examples/add-images-to-pages	images-on-pages.pdf
Image from memory	go run ./examples/image-from-memory	image-from-memory.pdf
Compression	go run ./examples/compress-optimize-pdf	compressed-optimized.pdf, uncompressed-debug.pdf
Import page	go run ./examples/import-page	import-page.pdf
Watermark	go run ./examples/watermark-pdf	watermarked.pdf
Merge pages	go run ./examples/merge-pdf-pages	merged-pages.pdf
Split and reorder pages	go run ./examples/split-reorder-pages	split-page-2.pdf, reordered-pages.pdf
Rotate pages	go run ./examples/rotate-pages	rotated-pages.pdf
4-up pages	go run ./examples/four-up-pages	four-up-pages.pdf
Template overlay	go run ./examples/template-overlay	template-overlay.pdf
Static form document	go run ./examples/form-creation	form-creation.pdf
Password protection	go run ./examples/protect-pdf	protected-password.pdf
Password and attachments	go run ./examples/protection-attachments	protection-attachments.pdf
Templates	go run ./examples/templates	templates.pdf
Thumbnail	go run ./examples/thumbnail	thumbnail.pdf
UTF-8 font	go run ./examples/utf8-font	utf8-font.pdf
Signing	go run ./examples/sign-pdf	signed.pdf
Rendering gallery	go run ./examples/rendering-gallery	many generated PDFs
External QR code module	cd examples/external-qr-code && go run .	qr-code.pdf

Use Document.RegisterQRCodePNG for QR-code verification blocks.

Packages

gopdfkit   root package: default constructor and public aliases
document   main PDF generation API
font       font parsing and JSON font definition generation
importpdf  small wrappers around imported-page APIs
inspect    lightweight PDF structure, stream, page, and text inspection
sign       CMS-first PDF signing and signature verification
sign/pkcs7 legacy PKCS #7 terminology wrappers around CMS APIs

Useful repository directories:

cmd/fontmaker          font definition generator
cmd/list               generated-reference listing utility
examples/              runnable examples
assets/static/         checked-in fonts, images, and text fixtures
assets/generated/pdf/  generated PDFs
doc/                   Markdown documentation
tools/                 tool-only module for quality/security commands

HTML Support

HTMLNew() renders a controlled subset of HTML fragments into PDF drawing operations. It is useful for rich text, generated sections, reports, letters, and static forms. It is not a browser engine.

Supported content includes inline text tags, links, paragraphs, headings, blocks, lists, tables, horizontal rules, images, figures, captions, opt-in local images, data URLs, and inline SVG.

Supported CSS is deliberately small: text styling, line height, alignment, vertical alignment, whitespace handling, simple colors, backgrounds, borders, border radius, simple box shadows, padding, margins, table/image dimensions, image fit modes, list marker style, and basic page-break controls.

Use document.RenderHTMLTemplate when HTML fragments need {{key}} substitution. Plain values are escaped, document.HTMLTemplateRaw inserts trusted HTML, and document.HTMLTemplateImage inserts an <img> tag that can be sized and spaced with supported HTML/CSS.

Use document.CompileHTML with HTML.WriteCompiled when the same fragment is rendered repeatedly. The compiled plan reuses tokenization, CSS selector matching, table parsing, inline SVG parsing, data URI image decoding, and cached block text. A CompiledHTML value is safe to reuse across documents and goroutines as long as callers do not mutate values returned by Tokens().

Compiled fragments expose lightweight diagnostics:

compiled, err := document.CompileHTML(fragment)
if err != nil {
    return err
}
stats := compiled.Stats()
issues := compiled.RecoveryIssues()
dump := compiled.DebugDump()
_, _, _ = stats, issues, dump

Stats reports reusable parse-product counts such as nodes, tables, images, inline SVGs, CSS rules, cached text, cached styles, and malformed-fragment recoveries. RecoveryIssues reports unclosed, misnested, or unexpected closing tags observed while building the private node model. DebugDump is intended for human diagnostics and should not be parsed as a stable wire format.

See doc/pdf-html-subset.md for the full contract.

Fonts

Standard PDF fonts require no setup:

pdf.SetFont("Helvetica", "", 12)

Use AddUTF8Font or AddUTF8FontFromBytes for UTF-8 TrueType fonts, including OpenType files with TrueType outlines. Use RTL() and LTR() to switch right-to-left rendering mode.

For non-UTF-8 TrueType, OpenType/CFF, or Type1 fonts, generate a JSON font definition with font.Make or cmd/fontmaker:

cd cmd/fontmaker
go build
./fontmaker --embed \
  --enc=../../assets/static/font/cp1252.map \
  --dst=../../assets/static/font \
  ../../assets/static/font/calligra.ttf

Signing

Documents can be signed while writing:

err := pdf.OutputSignedFile("signed.pdf", sign.Options{
	Signer:      signer,
	Certificate: cert,
})

The sign package uses CMS terminology and produces CMS SignedData:

cms, err := sign.CreateCMS(content, sign.CMSOptions{
	Signer:      signer,
	Certificate: cert,
	Detached:    true,
})

PDF signature helpers can extract /ByteRange content, compute digests, embed an externally produced detached CMS signature, inspect CMS signer metadata, and read the Adobe revocation-info archival signed attribute used by PAdES workflows:

cms, encoding, err := sign.DecodeCMS(rawSignature)
revInfo, err := sign.ExtractAdobeRevocationInfo(cms)
prepared, err := sign.ExtractSignature(pdfBytes)
signedPDF, err := sign.EmbedDetachedCMS(pdfBytes, cms)
result, err := sign.VerifyDetachedCMS(cms, prepared.SignedContent, roots)
cert, err := sign.SignerCertificate(cms)

For workflows that require exactly one PDF signature, use ExtractSingleSignature. Its ByteRange can be converted to the fixed [4]int64 form and reused for digesting or extracting signed content:

prepared, err := sign.ExtractSingleSignature(pdfBytes)
byteRange, err := prepared.ByteRange64()
digestHex, err := sign.DigestHexForByteRange(pdfBytes, byteRange, crypto.SHA256)
content, err := sign.SignedContentForByteRange(pdfBytes, byteRange)

Legacy PKCS #7 terminology is kept separate in sign/pkcs7. New code should prefer the CMS names in sign.

Inspection

Use inspect for lightweight PDF checks and text extraction from literal text operators:

count, err := inspect.PageCount(pdfBytes)
text, err := inspect.Text(pdfBytes)
streams, err := inspect.DecodedStreams(pdfBytes)

Errors

Most Document methods record errors on the document instead of returning errors directly. Once an error is set, later methods usually return without changing the PDF. Check Ok(), Err(), or Error() after generation, especially before trusting output.

Applications can transfer their own failures into the PDF object with SetError() or SetErrorf().

Development

Common commands:

go test ./...
go vet ./...
go list ./...
make check

Benchmarks:

make bench
make bench-ci
make bench-generation-core
make bench-generation-core-ci

make bench-generation-core runs non-HTML generation benchmarks only: baseline, text, UTF-8 text, images, SVG, templates, imported pages, protection, and attachments.

Some test examples generate or refresh PDFs under assets/generated/pdf. The document test package also clears generated PDFs before its example tests run.

Background

GoPDFKit is derived from the original FPDF PHP library and keeps many FPDF-style method names for compatibility and familiarity. Internally, this Go version uses buffers, io.Writer/io.WriteCloser output, and JSON font definition files.

License

GoPDFKit is released under the MIT License. See LICENSE.

Acknowledgments

This package's code and documentation are closely derived from the FPDF library created by Olivier Plathey. Many font and image resources are copied directly from FPDF.

The project also incorporates work or ideas from Bruno Michel, David Hernandez Sanz, Martin Hall-May, Andreas Wurmser, Manuel Cornes, Moritz Wagner, Klemen Vodopivec, Lawrence Kesteloot, Stefan Schroeder, Ivan Daniluk, Anthony Starks, Robert Lillack, Claudio Felber, Stani Michiels, Marcus Downing, Jan Slabon, Setasign, Jelmer Snoeck, Guillermo Pascual, Kent Quirk, Paulo Coutinho, Dan Meyers, David Fish, Andy Bakun, Paul Montag, Wojciech Matusiak, Artem Korotkiy, Dave Barnes, Brigham Thompson, Joe Westcott, and Benoit KUGLER.

Documentation

Overview

Package gopdfkit is a small facade over GoPDFKit's PDF generation API.

GoPDFKit generates PDFs directly from Go code. The root package exposes the default constructor and public aliases. Import github.com/cssbruno/gopdfkit/document for the full API.

Quick Start

pdf := gopdfkit.New()
pdf.AddPage()
pdf.SetFont("Helvetica", "B", 16)
pdf.Cell(40, 10, "Hello, world")
err := pdf.OutputFileAndClose("hello.pdf")

Use document.NewWithOptions when generation defaults should be configured at construction time:

pdf := document.NewWithOptions(document.Options{
    OrientationStr: "P",
    UnitStr:        "mm",
    SizeStr:        "A4",
    Optimize:       true,
})

Optimize selects best zlib compression for generated page and template streams. It is not a full PDF optimizer for images, fonts, object streams, or arbitrary existing PDFs.

Current Capabilities

The document package supports page generation, text, cells, multicells, tables, headers, footers, drawing primitives, clipping, transforms, transparency, gradients, spot colors, layers, templates, imported PDF pages, images, SVG, WebP, controlled HTML fragments, thumbnails, attachments, metadata, XMP metadata, JavaScript actions, password protection, PDF signing, and signature verification through CMS SignedData. The inspect package provides lightweight PDF structure, stream, page, and literal text inspection helpers.

Imported-page examples cover merge, split, reorder, rotate, 4-up layout, template overlay, and watermark overlay by creating a new PDF from imported pages.

Current Limits

GoPDFKit does not implement full browser HTML/CSS layout, JavaScript page rendering, DOCX conversion, interactive AcroForm field creation, filling or flattening existing interactive forms, FDF merging, unlocking/decrypting existing password-protected PDFs, OCR, arbitrary PDF content rewriting, or general-purpose semantic text extraction from every possible PDF encoding.

Imported page support is intentionally narrow: classic xref-table PDFs, unencrypted documents, and pages whose content streams are unfiltered or FlateDecode-compressed. PDFs that use xref streams or object streams are reported as unsupported.

Packages

The main packages are:

• gopdfkit: root facade with the default constructor and public aliases.
• document: main PDF generation API.
• font: font parsing and JSON font definition generation.
• importpdf: small wrappers around imported-page APIs.
• inspect: lightweight PDF structure, stream, page, and text inspection.
• sign: CMS-first PDF signing and signature verification.
• sign/pkcs7: legacy PKCS #7 terminology wrappers around CMS APIs.

Examples

Runnable examples live under examples/ and write PDFs under assets/generated/pdf/examples. Focused examples include reports, table reports, invoices, styled paragraphs, HTML/CSS styling, manual pagination, document-model pagination, images, compression, watermarks, merge/split/ reorder/rotate page workflows, 4-up pages, template overlays, static form documents, password protection, templates, thumbnails, UTF-8 fonts, and signing.

HTML Support

HTMLNew renders a controlled subset of HTML fragments into PDF drawing operations. It is useful for rich text, generated sections, reports, letters, and static forms. Supported CSS maps to PDF operations for text, colors, spacing, borders, border radius, backgrounds, simple box shadows, line height, page breaks, and table layout. It is not a browser engine.

Use document.RenderHTMLTemplate for simple {{key}} substitution before rendering HTML. Plain values are escaped, HTMLTemplateRaw inserts trusted HTML, and HTMLTemplateImage inserts an img tag that can be sized and spaced with supported HTML/CSS.

See doc/pdf-html-subset.md for the full renderer contract.

Errors

Most Document methods record errors on the document instead of returning errors directly. Once an error is set, later methods usually return without changing the PDF. Check Ok, Err, or Error after generation, especially before trusting output.

Background

GoPDFKit is derived from the original FPDF PHP library and keeps many FPDF-style method names for compatibility and familiarity. Internally, this Go version uses buffers, io.Writer/io.WriteCloser output, and JSON font definition files.

Index

• type Document
  • func New() *Document
  • func NewWithOptions(options Options) *Document
• type Options

Types

type Document

type Document = document.Document

Document is the high-level PDF document API exposed by the document package.

func New

func New() *Document

New returns a new PDF document using the document package defaults.

func NewWithOptions

func NewWithOptions(options Options) *Document

NewWithOptions returns a new PDF document using explicit construction options.

type Options

type Options = document.Options

Options customizes a new Document.
