lz4

A clean Go implementation of the LZ4 block format (CompressBlock / DecompressBlock), wire-compatible with the reference (cross-checked against pierrec/lz4). Its compressor delegates LZ4's hot "count the matching bytes" inner loop (LZ4_count) to matchlen, whose SIMD common-prefix kernel makes match extension fast.

As of matchlen v0.3.0, that kernel ships SIMD on all six of Go's 64-bit targets — amd64 (SSE2), arm64 (NEON), riscv64 (RVV), loong64 (LSX), ppc64le (VSX) and s390x (vector facility). lz4 needs no code change to benefit: MatchLen dispatches per-arch, so the bulk match now runs vectorized on ppc64le and s390x too. ppc64le is now natively measured on real POWER9 (GCC Compile Farm, VSX, Go 1.26.4, 2026-06-26): encode ~1.8× scalar (1174 vs 644 MB/s) and it beats pierrec/lz4 there (1174 vs 1012 MB/s) — the matchlen-accelerated extension pays off. riscv64 is now natively measured too on a SpacemiT X60 (RVV 1.0, a low-power in-order core — the only widely-available RVV silicon; GCC Compile Farm, Go 1.26.4, 2026-06-26): encode ~1.45× scalar (110 vs 76 MB/s) and it beats pierrec/lz4 there (110 vs 83 MB/s → ~1.32×); an out-of-order RVV core would likely do better. s390x stays qemu-validated for correctness only; native s390x throughput is pending (no GitHub-hosted IBM Z runner). The library is also build+test validated bit-exact on ppc64 (big-endian) on real POWER9 silicon (the generic/scalar fallback path) — six SIMD targets, validated on seven architectures.

c := lz4.CompressBlock(src)
out, _ := lz4.DecompressBlock(c, len(src))

Apple LZ4 frame format

macOS's Compression framework (COMPRESSION_LZ4) and Apple tooling built on it — such as Tart, whose disk layers are .compressed(using: .lz4) — do not emit a bare LZ4 block. They emit a frame: a sequence of bv41 (compressed), bv4- (stored) and bv4$ (end) blocks, little-endian, where a compressed block's matches may reference the previous block's output through a shared 64 KiB sliding window (LZ4 offsets are 16-bit). This is the LZ4 sibling of the bvx* frame that go-compressions/lzfse decodes.

// Streaming (bounded memory: one block + the 64 KiB window) — use this for
// large inputs such as Tart disk layers.
n, err := lz4.DecompressAppleStream(dst /* io.Writer */, src /* io.Reader */)

// Whole-buffer convenience.
out, err := lz4.DecompressApple(frameBytes)

Validated against real Apple output: a cirruslabs/macos-sequoia-base Tart disk layer decodes byte-for-byte to the length and SHA-256 recorded in its org.cirruslabs.tart.uncompressed-* OCI annotations.

Why LZ4 is the ideal matchlen consumer

LZ4 has no entropy-coding stage — encode time is dominated by match-finding and extension — so a faster MatchLen shows up end-to-end (unlike codecs whose time goes to FSE/Huffman).

The compressor

The parse is a single-cell hash table keyed on a 6-byte sequence (the reference LZ4 / pierrec fast-mode hash, far better dispersed than a 4-byte key). Each step probes three adjacent positions (ip, ip+1, ip+2) from one 8-byte load, inserting every position so later matches see more candidates, and ramps its skip distance on incompressible spans. On a hit it applies lazy matching — it peeks one byte ahead and, if ip+1 yields a strictly longer match, defers the current one — capped to short matches so the lookahead cost is only paid where it can help. Match-length extension is delegated to matchlen's SIMD kernel.

Performance

Encoded as single LZ4 blocks, three representative corpora — two text (Project Gutenberg pg1661, Mark Twain) and one binary (a kernel bzImage) — -count=8 medians, as of 2026-06-14.

Native arm64 (Apple Silicon, this host):

corpus	this package	pierrec/lz4	speed vs pierrec	our size	pierrec size	our size vs pierrec
text pg1661	208 MB/s	301 MB/s	0.69×	0.528	0.553	−4.6%
text Twain	205 MB/s	285 MB/s	0.72×	0.548	0.575	−4.6%
binary bzImage	249 MB/s	370 MB/s	0.67×	0.638	0.653	−2.2%

amd64 (QEMU x86_64 lima VM — TCG, so absolutes are low and noisy; the compressed output is byte-identical to arm64 and decodes both ways with pierrec): our encoder lands at ≈0.5–0.7× pierrec's TCG throughput, with the same size advantage as above (the parse is deterministic, so sizes match arm64 exactly).

Honest verdict. This pass beat pierrec on compression ratio on every corpus (text ≈4.6% smaller, binary ≈2.2% smaller) — the 6-byte hash, 3-position probe and lazy matching are real wins, and they fixed the prior parse, which was actually 7–8% worse than pierrec on text. We did not beat pierrec on speed: it stays ahead at ≈1.4× (we are at ~0.67–0.72× native arm64). That gap is the parse/table, not the kernel — pierrec uses a half-the-size 16-bit position table (better cache footprint) and skips lazy matching in fast mode, trading a little ratio for speed; we make the opposite trade. The SIMD matchlen extension is correct and in use, but match extension is only ~10% of encode time here — the bottleneck is match-finding. Blocks remain mutually decodable with pierrec in both directions, verified on arm64 and amd64. (matchlen ships SIMD on all six 64-bit Go targets. On native POWER9 ppc64le this encoder reaches 1174 MB/s — ~1.8× scalar and ahead of pierrec's 1012 MB/s there, since match-finding is comparatively less dominant on that core; on native riscv64 (SpacemiT X60, RVV 1.0 — a low-power in-order core, the only widely-available RVV silicon) it reaches 110 MB/s — ~1.45× scalar and ahead of pierrec's 83 MB/s (~1.32×); s390x native throughput stays pending. Build+test validated bit-exact on ppc64 big-endian too — six SIMD targets, seven validated architectures.)

License

BSD-3-Clause.

Documentation

Overview

Package lz4 implements the LZ4 block format (compress and decompress). The compressor's match extension — LZ4's hot "count the matching bytes" inner loop — is delegated to github.com/go-simd/matchlen, whose SIMD common-prefix kernel makes it fast on all six 64-bit Go targets.

The match-finder is a single-cell hash table keyed on a 6-byte sequence (the reference LZ4 / pierrec hash), probing several adjacent positions per step and using lazy matching — if position+1 yields a strictly longer match the shorter one is deferred — for a better ratio on text.

Index

• Variables
• func CompressBlock(src []byte) []byte
• func DecompressApple(src []byte) ([]byte, error)
• func DecompressAppleStream(dst io.Writer, src io.Reader) (int64, error)
• func DecompressBlock(src []byte, dstCap int) ([]byte, error)

Variables

var ErrAppleFrame = errors.New("lz4: malformed Apple LZ4 frame")

ErrAppleFrame reports a malformed Apple LZ4 frame (unknown block magic, truncated header/payload, or a block whose decoded length disagrees with its declared raw size).

Functions

func CompressBlock

func CompressBlock(src []byte) []byte

CompressBlock compresses src into a standard LZ4 block.

func DecompressApple

func DecompressApple(src []byte) ([]byte, error)

DecompressApple decodes an in-memory Apple LZ4 frame and returns the decompressed bytes. For large inputs prefer DecompressAppleStream, which does not buffer the whole output.

func DecompressAppleStream

func DecompressAppleStream(dst io.Writer, src io.Reader) (int64, error)

DecompressAppleStream decodes Apple's LZ4 frame format from src, writing the decompressed bytes to dst, and returns the number of bytes written. It streams block by block, holding at most one block plus the 64 KiB cross-block window in memory, so it is safe for multi-gigabyte inputs (e.g. Tart disk layers).

A well-formed frame ends with a "bv4$" marker; a stream that ends before one (including an empty stream) is reported as ErrAppleFrame.

func DecompressBlock

func DecompressBlock(src []byte, dstCap int) ([]byte, error)

DecompressBlock decompresses an LZ4 block. dstCap is a hint for the output capacity (the decompressed size if known).

The decode hot loop follows pierrec/lz4's pure-Go structure, which is ~2× faster than a naive append-based loop: the output is written by *index* into a preallocated buffer (no per-token slice-append cap checks), and the two dominant cases — a literal run of ≤16 bytes and a non-overlapping match of ≤16 bytes — each take a *fixed* 16-byte copy that the compiler lowers to a couple of word moves, with no length-variable copy() call and no overlap loop. Longer/overlapping runs fall to the bulk copy paths.

The buffer is overallocated by decodeSlack bytes so those unconditional 16-byte copies never run off the end; the real output length is di.
