README

go-filesystems/cab

cab

A pure-Go reader for the Microsoft Cabinet (.cab) format, presenting a cabinet as a filesystem.Filesystem.

No cgo, no dependencies outside the standard library and go-filesystems/interface. MSZIP is raw DEFLATE, and compress/flate is exactly the decoder it asks for.

f, err := os.Open("driver.cab")
st, _ := f.Stat()

fs, err := cab.OpenReader(f, st.Size())   // filesystem.Filesystem, error
if err != nil {
    return err
}
defer fs.Close()

data, err := fs.ReadFile("sub/dir/readme.txt")

OpenReader(r io.ReaderAt, size int64) (filesystem.Filesystem, error) is the shape every driver in this org answers to, so go-filesystems/detect can open them all through one function type. cab.Open is the same call returning the concrete *FS, for the cabinet-specific accessors below.

*FS also implements the optional filesystem.Opener, so a caller that must answer a 4 KiB request out of a 4 GiB member can:

if o, ok := fs.(filesystem.Opener); ok {
    h, err := o.OpenFile("big.bin")   // reads nothing
    defer h.Close()
    n, err := h.ReadAt(buf, off)      // io.ReaderAt, to the letter
}

Beyond the interface: SetID, CabinetIndex, Version, PrevCabinet, PrevDisk, NextCabinet, NextDisk, Reserved, FolderCount, Compression(path), Attributes(path), ModTime(path).

A cabinet is read-only. WriteFile, MkDir, DeleteFile, DeleteDir and Rename return ErrReadOnly.

Scope: None and MSZIP are read, Quantum and LZX are not

A CFFOLDER names one of four compression methods, and this package reads two:

typeCompress method read here
0 None (stored) yes
1 MSZIP (CK + raw DEFLATE) yes
2 Quantum no — refused by name
3 LZX no — refused by name

Quantum and LZX are out of scope as a decision, not an omission. Each is a substantial algorithm in its own right — LZX especially, with tree-delta coding, aligned-offset blocks and E8 call-offset translation — and nothing in this ecosystem produces or consumes them: the cabinets in circulation here come from gcab and from makecab's default, which write MSZIP or store. A cabinet using either is refused at OpenReader with ErrCompressionUnsupported, and the message names the method and the folder it was found in:

cab: folder 0 uses LZX, which is a complete algorithm this package does not
implement: cab: compression method not read by this package

Three sentences this package keeps apart

A reader that answers "bad file" to everything leaves its caller nothing to decide with, so the failures are divided by what a caller can act on.

sentence sentinels what it means
I do not know what this is ErrNotCabinet, ErrUnknownCompression the magic is not MSCF, or a typeCompress the format does not define. Try another reader.
I know exactly what this is and do not read it yet ErrCompressionUnsupported, ErrSpansCabinets Quantum or LZX; or a member continued from/into another cabinet of the set, which one io.ReaderAt cannot reach. The file is fine; this package is the limit.
this file is broken ErrTruncated, ErrCorrupt a structure runs past the end; a field, a checksum or a DEFLATE stream contradicts the rest. Nothing will read it.

Plus the ordinary path errors: ErrNotFound (which satisfies errors.Is(err, io/fs.ErrNotExist), the contract every driver in this org owes its callers), ErrNotDirectory, ErrNotRegular, ErrNotSymlink, ErrReadOnly, ErrNegativeOffset.

An I/O error from the underlying reader is returned as itself, never relabelled ErrCorrupt: a caller told the cabinet is broken when the disk is what failed goes looking in the wrong place.

Three traps, and the tests that would catch each

The reserve sizes change the size of every later structure

cfhdrRESERVE_PRESENT (flags 0x0004) is followed by cbCFHeader, cbCFFolder and cbCFData, and each inserts an opaque area into every instance of the structure it names — after the header's fixed fields, after every CFFOLDER, and, for cbCFData, between every CFDATA header and its compressed bytes. A reader that skips the header's own area and forgets the other two lands one field out for the rest of the file.

⚠ A single-folder cabinet cannot detect a reader that ignores cbCFFolder. The area sits after the last structure that uses it, and coffFiles is absolute, so nothing moves. The first version of testdata/reserve.cab had one folder, and that ablation passed — the finding is in the ablation table below. It now has two.

MSZIP history crosses block boundaries

A folder's uncompressed stream is the concatenation of its CFDATA blocks' output, and under MSZIP the DEFLATE history carries across those blocks: block N may reference bytes emitted by block N−1. flate.NewReaderDict, seeded with exactly the preceding 32 KiB of folder output, is the remedy.

⚠ Size is not the property that makes a fixture see this — the writer is. testdata/mszip.cab is 250 KB over eight blocks, and it decodes perfectly with the window thrown away, because gcab's compressor never emits a back-reference into the preceding block. testdata/history.cab does, and there block 1 will not inflate at all without the dictionary.

The checksum's trailing bytes are not folded little-endian

CFDATA.csum is a 32-bit XOR of the block's little-endian words, but the trailing 1–3 bytes are folded high byte first — the specification's reference code walks them with a pointer, so the first leftover byte takes the highest position. Folding them little-endian instead agrees for every cbData that is ≡ 0 or 1 (mod 4), which was 22 of the 41 blocks in this corpus.

A recorded csum of 0 means "not computed" and is not compared; a non-zero one is verified.

Random access costs what the format costs

A folder is a stream. Under MSZIP, reaching byte n means inflating the n bytes before it, because the history window makes no block independently decodable. A handle keeps its decoder and its position, so reading forwards is linear overall while reading backwards starts a fresh pass from the start of the folder. Under None there is no history, so a handle restarts at the block containing the offset and reads at most one block it does not need.

Opener is implemented anyway rather than withheld, because the alternative for a caller serving small requests is ReadFile, which holds the whole member in memory. ReadAt is safe to call concurrently, as io.ReaderAt requires.

Names

A CFFILE name is NUL-terminated and uses backslash as its separator; this package converts to / and cleans the result, so sub\deep\file.txt is reached as sub/deep/file.txt. A cabinet holds no directory entries at all, so the directories a listing needs are synthesised from the paths that are there.

The encoding is chosen by one attribute bit: with _A_NAME_IS_UTF (0x80) the name is UTF-8 — and is rejected if it is not valid UTF-8 — and without it, Windows-1252. The five byte values Windows-1252 leaves undefined (0x81, 0x8D, 0x8F, 0x90, 0x9D) decode to U+FFFD.

Fixtures, and the readers that vouch for them

Every fixture's premise is asserted before anything judges the decoder: the method actually recorded in the CFFOLDER is read back from the file, and the payload is large enough that a folder spans several CFDATA blocks. A writer asked for MSZIP stores a small member anyway, and a corpus of small members passes every method while only None ever runs.

fixture written by folders asserted by
mszip.cab gcab -c -z 1 × MSZIP, 8 blocks 7-Zip 26.03, cabextract 1.11, bsdtar
store.cab gcab -c 1 × None, 8 blocks 7-Zip; and it is the byte-for-byte reference the MSZIP decode is compared against
paths.cab gcab -c -z 1 × MSZIP backslash paths and a UTF-8-flagged name
reserve.cab crafted 2 (MSZIP + None), all three reserve areas gcab 1.6, cabextract 1.11
history.cab crafted, flate.NewWriterDict 1 × MSZIP, 8 blocks, genuine cross-block references gcab 1.6, 7-Zip 26.03, libarchive 3.7.4

Two disagreements between reference readers turned up while these were being checked, and both are recorded here because a reader that trusts a single witness would have drawn the wrong conclusion from either:

  • 7-Zip 26.03 reports Data Error on any cabinet carrying a per-CFDATA reserve area. The specification puts abReserve between cbUncomp and ab[]; gcab and cabextract both read it that way, and so does this package.
  • cabextract 1.11 (libmspack) stops after block 0 with decompression error on any cabinet whose MSZIP blocks reference the preceding block. gcab, 7-Zip and libarchive all read those correctly.

Fixtures are embedded with //go:embed, because the emulated CI lanes run a go test -c binary in a container with no testdata/. Verify with:

go test -c -o /tmp/t.test . && cd /tmp && ./t.test

Ablation table

For every decision the reader makes, the test suite undoes it and checks that the corpus notices. An ablation that passes is the finding: it says the fixture cannot see the mistake, so the test guarding it is decoration. go test -v -run TestZZZAblationTable prints the table; record fails the run when an ablation meant to be caught is not, and when one documented as invisible suddenly is.

ablation detected by what
cbCFHeader ignored yes refused: folder 0 records typeCompress(5)
cbCFFolder ignored yes refused: a structure at offset 2880154539 runs past the end
cbCFData ignored yes refused: block 2 holds 49298 bytes past the end
all three ignored yes refused: unknown compression
backslash left unconverted yes the unconverted name is not a path this filesystem answers to
MSZIP history dropped, on mszip.cab no — as documented the same bytes came back: gcab emits no cross-block references
MSZIP history dropped, on history.cab yes refused: block 1 will not inflate
MSZIP window truncated to 0 / 1 Ki / 8 Ki / 16 Ki / 32767 B yes (each) refused: block 1 will not inflate
uoffFolderStart ignored (both methods) yes wrong bytes, differing at byte 0
CK signature corrupted yes refused — by the checksum, which is why the next row exists
CK corrupted and the checksum zeroed yes refused: block does not begin with CK
CK fed to the inflater yes flate: corrupt input before offset 3
UTF-8 name read as Windows-1252 yes the name no longer resolves: sub/café.txt
Windows-1252 name read as UTF-8 yes refused as invalid UTF-8
one byte flipped inside a block yes refused: checksum mismatch
checksum trailing bytes folded little-endian yes of 41 blocks, by cbData mod 4: {0: 8 agree / 0 differ} {1: 14/0} {2: 7/6} {3: 0/6}

Regenerating the fixtures

gcab -c -z mszip.cab big.txt small.txt
gcab -c    store.cab big.txt small.txt
gcab -c -z paths.cab big.txt sub/deep/nested.txt sub/café.txt

reserve.cab re-frames mszip.cab with two folders and all three reserve areas; history.cab frames a payload whose every 32 KiB block repeats the block before it, each compressed with flate.NewWriterDict seeded with that preceding block. Both were extracted by the outside readers listed above and compared byte for byte before being committed. The payload sha256 sums are pinned in fixtures_test.go, so a fixture regenerated over a different payload fails loudly rather than quietly measuring something else.

Licence

BSD-3-Clause.

Documentation

Overview

Package cab is a pure-Go reader for the Microsoft Cabinet (.cab) format, presenting a cabinet as a filesystem.Filesystem.

It needs nothing outside the standard library: MSZIP is raw DEFLATE, and compress/flate is exactly the decoder it asks for. CGO_ENABLED=0 throughout.

fs, err := cab.OpenReader(f, size)   // f is an io.ReaderAt
data, err := fs.ReadFile("sub/dir/file.txt")

FS also implements the optional filesystem.Opener, so a caller that must answer a byte range without materialising a whole entry can, subject to what the format costs (see "Random access", below).

Scope: None and MSZIP are read; Quantum and LZX are not

A CFFOLDER names one of four compression methods. This package reads two of them:

  • None (typeCompress 0): the folder's blocks are stored.
  • MSZIP (1): each block is the two bytes "CK" followed by a raw DEFLATE stream.

Quantum (2) and LZX (3) are NOT read, and this is a decision rather than an omission. Each is a substantial algorithm in its own right -- LZX especially, with its own tree-delta coding, aligned-offset blocks and E8 call-offset translation -- and nothing in this ecosystem produces or consumes them: the cabinets in circulation here come from gcab and from makecab's default, both of which write MSZIP or store. A cabinet using either one is refused at OpenReader with ErrCompressionUnsupported, and the error NAMES the method and the folder it found it in.

Three sentences this package keeps apart

A reader that answers "bad file" to every question is useless to whoever has to decide what to do next, so the failures are divided by what the caller can act on:

  • "I do not know what this is" -- ErrNotCabinet (the four magic bytes are not "MSCF", or the file is too small to hold them) and ErrUnknownCompression (a typeCompress this format revision does not define). Try another reader, or another file.
  • "I know exactly what this is and do not read it yet" -- ErrCompressionUnsupported (Quantum, LZX) and ErrSpansCabinets (an entry continued from, or into, another cabinet of the same set, which one io.ReaderAt cannot reach). The file is fine; this package is the limit.
  • "this file is broken" -- ErrTruncated (a structure runs past the end) and ErrCorrupt (a field, a checksum or a DEFLATE stream contradicts the rest). Nothing will read it.

Reserve fields change the size of every later structure

When the header carries CFHEADER flag cfhdrRESERVE_PRESENT (0x0004) it is followed by three sizes -- cbCFHeader, cbCFFolder, cbCFData -- and each one inserts an opaque area into EVERY instance of the structure it names: after the header's fixed fields, after every CFFOLDER, and, for cbCFData, between every CFDATA header and its compressed bytes. A reader that skips the header's own reserve area and forgets the other two lands one field out for the rest of the file, which is the classic way a cabinet reader fails. All three are honoured here, and testdata/reserve.cab exercises all three at once.

That fixture also recorded a disagreement between reference readers: libgcab and libmspack (cabextract) both read the per-CFDATA reserve area as the specification describes it, and 7-Zip 26.03 reports "Data Error" on the same file. The specification's CFDATA layout puts abReserve between cbUncomp and ab[], two of three readers agree with it, and so does this package.

MSZIP history crosses block boundaries

A folder's uncompressed stream is the concatenation of its CFDATA blocks' output, and under MSZIP the DEFLATE history carries ACROSS those blocks: block N may reference bytes emitted by block N-1. Each block is its own DEFLATE stream, so a decoder that simply starts a fresh one per block is correct for any file small enough to fit in one block -- which is every hand-made test fixture -- and silently wrong beyond that. The remedy is flate.NewReaderDict, seeded with exactly the preceding 32 KiB of folder output; this package keeps that window and testdata/mszip.cab spans eight blocks so that dropping it fails.

Random access costs what the format costs

A folder is a STREAM. Under MSZIP, reaching byte n of a folder means inflating the n bytes before it, because the history window makes no block independently decodable; a handle therefore keeps its decoder and its position, so reading forwards is linear overall while reading BACKWARDS starts a fresh pass from the start of the folder. Under None there is no history, so a handle restarts at the block containing the offset and reads at most one block's worth it does not need.

Opener is implemented anyway, rather than withheld, because the alternative for a caller serving 4 KiB requests is ReadFile -- which holds the WHOLE entry in memory. A bounded rescan is worse than nothing only if the caller expected a seek to be free, and this paragraph exists so that it does not.

Read-only

A cabinet is read-only: every mutating method of filesystem.Filesystem (WriteFile, MkDir, DeleteFile, DeleteDir, Rename) returns ErrReadOnly, as in the other read-only drivers of this org.

Names

A CFFILE name is a NUL-terminated byte string using BACKSLASH as its path separator; this package converts to '/' and cleans the result, so a cabinet's "sub\deep\file.txt" is reached as "sub/deep/file.txt". A cabinet holds no directory entries of its own, so the directories a listing needs are synthesised from the paths that are there.

The encoding is chosen by one attribute bit: with _A_NAME_IS_UTF (0x80) the name is UTF-8, and without it Windows-1252. The five byte values Windows-1252 leaves undefined (0x81, 0x8D, 0x8F, 0x90, 0x9D) decode to U+FFFD.

Index

Constants

This section is empty.

Variables

View Source
var (
	// ErrNotCabinet says the bytes are not a cabinet at all: the file is
	// shorter than the four magic bytes, or those bytes are not "MSCF".
	// "I do not know what this is."
	ErrNotCabinet = errors.New("cab: not a Microsoft Cabinet file")

	// ErrUnknownCompression says a CFFOLDER named a compression method this
	// format revision does not define (typeCompress low nibble 4..15).
	// "I do not know what this is" -- about one folder rather than the file.
	ErrUnknownCompression = errors.New("cab: unknown compression method")

	// ErrCompressionUnsupported says the cabinet is well-formed and uses a
	// method this package does not implement: Quantum or LZX. The error text
	// names which one, and which folder. "I know exactly what this is and do
	// not read it yet."
	ErrCompressionUnsupported = errors.New("cab: compression method not read by this package")

	// ErrSpansCabinets says an entry is continued from, or into, another
	// cabinet of the same set. One io.ReaderAt is one file and the rest of the
	// set is in other files, so this reader cannot complete such an entry --
	// and does not pad it with zeros and call that a success.
	ErrSpansCabinets = errors.New("cab: entry continues in another cabinet of the set")

	// ErrTruncated says a structure the cabinet points at runs past the end of
	// the bytes available. "This file is broken."
	ErrTruncated = errors.New("cab: cabinet is truncated")

	// ErrCorrupt says a field, a block checksum or a DEFLATE stream
	// contradicts the rest of the file. "This file is broken."
	ErrCorrupt = errors.New("cab: cabinet is corrupt")

	// ErrReadOnly is returned by every mutating method (WriteFile, MkDir,
	// DeleteFile, DeleteDir, Rename). A cabinet is a read-only format.
	ErrReadOnly = errors.New("cab: cabinet is read-only")

	// ErrNotFound is returned when a path is not in the cabinet. It satisfies
	// errors.Is(err, io/fs.ErrNotExist), which is the error contract every
	// driver in this org owes its callers.
	ErrNotFound = fmt.Errorf("cab: path not found: %w", iofs.ErrNotExist)

	// ErrNotDirectory is returned when ListDir targets something that is not a
	// directory.
	ErrNotDirectory = errors.New("cab: not a directory")

	// ErrNotRegular is returned when ReadFile or OpenFile targets a directory.
	ErrNotRegular = errors.New("cab: not a regular file")

	// ErrNotSymlink is returned by ReadLink for every path: the cabinet format
	// records no symbolic links, so there is never one to read.
	ErrNotSymlink = errors.New("cab: not a symbolic link")

	// ErrNegativeOffset is returned by File.ReadAt for a negative offset.
	ErrNegativeOffset = errors.New("cab: negative offset")
)

Sentinel errors. Compare with errors.Is so wrapped errors continue to match.

They are divided by what a caller can DO about the failure; see the package documentation, "Three sentences this package keeps apart".

Functions

func OpenReader

func OpenReader(r io.ReaderAt, size int64) (filesystem.Filesystem, error)

OpenReader reads the cabinet in the first size bytes of r.

This is the shape every driver in go-filesystems answers to, so github.com/go-filesystems/detect can open them all through one function type. It reads the header, every CFFOLDER with its block table and every CFFILE, and no file data at all: the returned filesystem decodes on demand.

r must stay valid and readable for as long as the returned filesystem is used; Close does not touch it, because OpenReader never took ownership of it.

A cabinet whose folders use Quantum or LZX is refused here, by name -- see the package documentation for why those two are out of scope.

Types

type Compression

type Compression uint16

Compression is the method a CFFOLDER records in the low nibble of its typeCompress field.

const (
	CompressionNone    Compression = 0
	CompressionMSZIP   Compression = 1
	CompressionQuantum Compression = 2
	CompressionLZX     Compression = 3
)

The four methods the format defines. This package reads the first two; see the package documentation for why it refuses the other two by name.

func (Compression) String

func (c Compression) String() string

String names the method, so an error can say which one it met.

type FS

type FS struct {
	// contains filtered or unexported fields
}

FS reads a Microsoft Cabinet as a filesystem.

It satisfies filesystem.Filesystem and the optional filesystem.Opener. See the package documentation, "Random access costs what the format costs", for what a seek inside a compressed folder actually does.

func Open

func Open(r io.ReaderAt, size int64) (*FS, error)

Open is OpenReader returning the concrete type, for callers that want the cabinet-specific accessors -- SetID, PrevCabinet, Compression, Reserved -- that filesystem.Filesystem has no room for.

func (*FS) Attributes

func (f *FS) Attributes(p string) (uint16, error)

Attributes is the CFFILE attribute word recorded for path.

func (*FS) CabinetIndex

func (f *FS) CabinetIndex() uint16

CabinetIndex is this cabinet's position within its set, counting from zero.

func (*FS) Close

func (f *FS) Close() error

Close releases nothing: FS never took ownership of the io.ReaderAt it was given, and each read decodes into memory it drops on the way out.

func (*FS) Compression

func (f *FS) Compression(p string) (Compression, error)

Compression reports the method recorded in the CFFOLDER that holds path.

It exists so that a test can assert the PREMISE of a fixture rather than assume it: a writer asked for MSZIP may store a small entry anyway, and a corpus of such entries passes every method while only None ever runs.

func (*FS) DeleteDir

func (f *FS) DeleteDir(string) error

func (*FS) DeleteFile

func (f *FS) DeleteFile(string) error

func (*FS) FolderCount

func (f *FS) FolderCount() int

FolderCount is how many CFFOLDER streams the cabinet holds.

func (*FS) ListDir

func (f *FS) ListDir(p string) ([]filesystem.DirEntry, error)

ListDir names what is directly inside p, sorted.

func (*FS) MkDir

func (f *FS) MkDir(string, os.FileMode) error

func (*FS) ModTime

func (f *FS) ModTime(p string) (time.Time, error)

ModTime is the modification time recorded for path. The format's packed MS-DOS date and time have two-second resolution and no timezone, so the result is in UTC.

func (*FS) NextCabinet

func (f *FS) NextCabinet() string

NextCabinet is the file name of the cabinet after this one in its set, and "" when the header does not name one.

func (*FS) NextDisk

func (f *FS) NextDisk() string

NextDisk is the media name recorded beside NextCabinet.

func (*FS) OpenFile

func (f *FS) OpenFile(p string) (filesystem.File, error)

OpenFile hands back a random-access handle on one entry, reading none of it.

func (*FS) PrevCabinet

func (f *FS) PrevCabinet() string

PrevCabinet is the file name of the cabinet before this one in its set, and "" when the header does not name one. PrevDisk is the accompanying media name, which is prompt text rather than a path.

func (*FS) PrevDisk

func (f *FS) PrevDisk() string

PrevDisk is the media name recorded beside PrevCabinet.

func (*FS) ReadFile

func (f *FS) ReadFile(p string) ([]byte, error)

ReadFile returns the whole entry.

It holds the entry in memory, which for a large member of a compressed folder is the whole member. Use OpenFile for anything whose size you did not choose.

func (f *FS) ReadLink(p string) (string, error)

ReadLink always refuses: the cabinet format records no symbolic links, so there is never one to read. The method exists because filesystem.Filesystem requires it.

func (*FS) Rename

func (f *FS) Rename(string, string) error

func (*FS) Reserved

func (f *FS) Reserved() []byte

Reserved is the opaque area the header's cbCFHeader reserved, or nil. The bytes belong to whatever wrote the cabinet; this package only skips them correctly.

func (*FS) SetID

func (f *FS) SetID() uint16

SetID is the cabinet set this file belongs to: every cabinet of one set carries the same value.

func (*FS) Stat

func (f *FS) Stat(p string) (filesystem.Stat, error)

Stat reports what the cabinet recorded about p.

func (*FS) Version

func (f *FS) Version() (major, minor uint8)

Version is the format version the header records, major first. The specification describes 1.3.

func (*FS) WriteFile

func (f *FS) WriteFile(string, []byte, os.FileMode) error

The mutating half of filesystem.Filesystem. A cabinet is read-only, as in the other read-only drivers of this org.

Source Files

View all Source files

Jump to

Keyboard shortcuts

? : This menu
/ : Search site
f or F : Jump to
y or Y : Canonical URL
go.dev uses cookies from Google to deliver and enhance the quality of its services and to analyze traffic. Learn more.
